| Specifications |
Dimensions |
Pod: 96.4 x 96 x 147mm / GCU: 45.4 x 40 x 13.5mm |
| Weight |
Pod: 608g / GCU: 18.6g |
| Operating Voltage |
14 ~ 53 VDC |
| Mounting |
Downward / Upward |
| Operating Temperature |
Minus 20℃～50℃ |
| Storage Temperature |
Minus 40℃～60℃ |
| Operating Humidity |
≤85%RH (Non-condensing) |
| Control Method |
UART / S.BUS / TCP |
| Gimbal |
Gimbal Type |
3-axis Mechanical Stabilization |
| Angular Accuracy |
±0.01° |
| Controllable Range |
Pitch: -150°～+50°, Yaw: ±360° constantly |
| Zoom Camera |
Image Sensor |
1/2.8” CMOS; Effective Pixels: 2.07M |
| Lens |
Focal Length: 4.7~47mm
HFOV: 61.3°～6.8°
VFOV: 36.9°～3.9°
DFOV: 68.4°～7.8°
|
| Resolution |
1920 x 1080 |
| Pixel Pitch |
2.9μm |
| Optical Zoom Rate |
10x |
| Equivalent Digital Zoom Rate |
3x |
| Thermal Camera |
Thermal Sensor |
Uncooled VOx Microbolometer |
| Lens |
Focal Length: 18mm
HFOV: 24°
VFOV: 18°
DFOV: 30.4°
|
| Resolution |
640 x 512 |
| Sensitivity (NETD) |
<50mk@25℃ |
| Detection |
Person: 750m; Light vehicle: 2300m; Large vehicle: 4900m |
| Identification |
Person: 188m; Light vehicle: 575m; Large vehicle: 1225m |
| Recognition |
Person: 94m; Light vehicle: 288m; Large vehicle: 613m |
| DRI (EN62676-4:2015) |
Detection |
Person: 709m; Light vehicle: 932m; Large vehicle: 1986m |
| Identification |
Person: 142m; Light vehicle: 187m; Large vehicle: 397m |
| Recognition |
Person: 71m; Light vehicle: 93m; Large vehicle: 199m |
| Detection and Tracking |
Object Size |
16x16 ~ 128x128 px |
| Object Identification Delay |
<40ms |
| Tracking Speed |
±32 px / field |
| Tracking Deviation Refresh Rate |
30Hz |
| Tracking Deviation Output Delay |
≤5ms |
| Image & Video |
Image Format |
JPEG |
| Maximum Image Resolution |
1920 x 1080 |
| Video Format |
MP4 |
| EXIF |
Shooting point coordinate |
| Maximum Video Resolution |
1080P @ 25fps |
| Stream Encode Format |
H.264, H.265 |
| Stream Network Protocol |
RTSP |
| Laser Range Finder |
Wavelength |
905nm |
| Max Laser Power |
1mW |
| Beam Angle |
3.5mrad |
| Beam Diameter |
0.35m @ 100m |
| Laser Safety |
Class 1M (IEC 60825-1:2014) |
| Measurement Accuracy |
±1.0m |
| Measurement Range |
5-1200m (ϕ12m vertical surface with 20% reflectivity) |
| Storage |
Supported SD Cards |
Class 10 MicroSD card with a capacity of up to 256GB |
| Support File System |
HDD-FAT32 |
