| Specifications |
Dimensions |
142 x 125 x 187mm |
| Weight |
1055g |
| Operating Voltage |
20 ~ 53 VDC |
| Mounting |
Downward / Upward |
| Operating Temperature |
-20℃～50℃ |
| Storage Temperature |
-40℃～60℃ |
| Operating Humidity |
≤85%RH (Non-condensing) |
| Control Method |
UART / S.BUS / TCP |
| Gimbal |
Gimbal Type |
3-axis Mechanical Stabilization |
| Angular Accuracy |
±0.01° |
| Controllable Range |
Pitch: -120°～40°, Roll: ±40°, Yaw: ±360° constantly |
| Zoom Camera |
Image Sensor |
1/2.8-inch CMOS, Effective Pixels: 4.09M |
| Lens |
Actual Focal Length: 4.7~141mm (Equivalent focal length: 27.9~837mm)
Aperture: f/1.5~f/4.0
HFOV: 59.5°～2.2°
VFOV: 35.8°～1.2°
DFOV: 66.6°～2.5°
|
| Resolution |
2688(H) x 1520(V) |
| Optical Zoom Rate |
30x |
| Equivalent Digital Zoom Rate |
4x |
| Thermal Camera |
Thermal Sensor |
Uncooled VOx Microbolometer |
| Lens |
Focal Length: 25mm (Equivalent focal length: 93.2mm)
Aperture: f/1.0
HFOV: 17.5°
VFOV: 14.0°
DFOV: 22.3°
|
| Resolution |
640 x 512 |
| Sensitivity (NETD) |
<50mk@F1.0@25℃ |
| Detection |
Person: 1042m; Light vehicle: 3194m; Large vehicle: 6806m |
| Identification |
Person: 260m; Light vehicle: 799m; Large vehicle: 1701m |
| Recognition |
Person: 130m; Light vehicle: 399m; Large vehicle: 851m |
| DRI (EN62676-4:2015) |
Detection |
Person: 3283m; Light vehicle: 4315m; Large vehicle: 9192m |
| Identification |
Person: 657m; Light vehicle: 863m; Large vehicle: 1838m |
| Recognition |
Person: 328m; Light vehicle: 432m; Large vehicle: 919m |
| Image & Video |
Image Format |
JPEG |
| Maximum Image Resolution |
1920 x 1080 |
| Video Format |
MP4 |
| EXIF |
Shooting point coordinate |
| Output Video Resolution |
Stream: 1920 x 1080 @25fps |
| Maximum Video Resolution |
Recording: 1920 x 1080 @30fps |
| Stream Encode Format |
H.264, H.265 |
| Stream Network Protocol |
RTSP |
| Laser Range Finder |
Wavelength |
905nm |
| Max Laser Power |
1mW |
| Beam Angle |
2.5m rad |
| Laser Safety |
Class 1M (IEC 60825-1:2014) |
| Measurement Accuracy |
±0.3m(＜300m) / ±1.0m(＞300m) |
| Measurement Range |
5-1800m (ϕ12m vertical surface with 20% reflectivity) |
| Storage |
Supported SD Cards |
Speed Class 10 MicroSD card with a capacity of up to 256G8 |
